Name: Kingsman Zero Clearance Clean View Direct Vent Millivolt Gas Fireplace - 42 Inch - ZCV42H
SKU: ZCV42NH
Availability: InStock

Free Venting Design & Quote:

Manufacturer: Kingsman
Part Numbers: ZCV42LPH, ZCV42NH
eFireplaceStore Item Number: KGM-ZCV42NH

Features

Color: Black(ZCV42LPH, ZCV42NH)
Product Dimensions: 42 1/2″ W x 41″ H x 18 1/2″ D(ZCV42LPH, ZCV42NH)
Direct vent gas fireplace
Choose between natural and propane gas
Ceramic glass design offer superior heat transfer
Fireplace heater rated for use as a supplemental heat source
Able to be equipped with a full line of remotes and wall switches
Low profile fireplace frame allows for a clean looking installation
Includes safety barrier screen to prevent accidental contact with hot glass
Able to utilize one of two detailed 5 piece log sets or contemporary glass media
Reliable standing pilot valve system ensures ready operation during power outages

Technical Specifications

Maximum BTU Output: 18,000
Min/Max Natural Gas Inlet Pressure: 5.5″/9″ WC
Min/Max Propane Inlet Pressure: 11″/12″ WC
Framing Dimensions: 42 1/2″ W x 41″ H x 18 1/2″ D
Venting Dimensions: 4″ ID
Approved Direct Vent Systems: Kingsman flex (Z-Flex) venting kit, M & G-Duravent, Direct Vent system (Duravent Pro), BDM Pro Form Direct Vent, Ameri-Vent Direct Vent Pipe System, ICC Excel Direct, Metal Fab Sure-Seal DV and Selkirk Direct Temp
Actual Viewing Area: 3 1/8″ W x 31 3/4″ H
Valve Type: Millivolt (Standing Pilot)

*Venting Requirements: This unit requires venting pipe with an inner diameter of 4 Inches. Please see the Venting Components section on this page if available for venting pipe that must be used with this unit.

This 42-Inch Kingsman Zero Clearance Clean View Direct Vent Millivolt Gas Fireplace, rated for use as a supplemental heat source, with a low profile frame for a clean looking installation and ceramic glass for superior heat transfer is an excellent choice of fireplace heater. This ZCV42H Fireplace utilizes your choice of one of two highly detailed 5-piece log sets or contemporary glass media and pairs with a full line of remotes and wall switches. The reliable standing pilot valve system ensures system operation is possible even through power outages. Kingsman includes safety barrier screens to prevent accidental contact with hot surfaces. BTU Input Ratings: 29,500 Natural Gas / 29,000 Liquid Propane. Efficiency Rating: 65.2% Natural Gas / 65.2% Liquid Propane.
