Name: Kingsman Zero Clearance Clean View Direct Vent Millivolt Gas Fireplace - 36 Inch - ZCV3622
SKU: ZCV3622N
Availability: InStock

Free Venting Design & Quote:

Manufacturer: Kingsman
Part Numbers: ZCV3622LP, ZCV3622N
eFireplaceStore Item Number: KGM-ZCV3622N

Features

Color: Black(ZCV3622N, ZCV3622LP)
Product Dimensions: 36″ W 37 1/8″ H and 17 7/16″ D(ZCV3622N, ZCV3622LP)
Direct vent gas fireplace
Choose between natural or propane gas
Tempered glass front with smooth face perimeter
Fireplace heater rated for use as a supplemental heat source
Low profile fireplace frame allows for a clean looking installation
Able to be equipped with a full line of remotes and wall switches
Utilizes a lifelike split oak log set made of durable cast refractory cement
Includes safety barrier screen to prevent accidental contact with hot glass
Reliable standing pilot valve system ensures ready operation during power outages

Technical Specifications

Maximum BTU Output: 18,000
Min/Max Natural Gas Inlet Pressure: 5.5″/9″ WC
Min/Max Propane Inlet Pressure: 11″/12″ WC
Framing Dimensions: 36 3/8″ W x 37 1/4″ H x 17 1/2″ D
Venting Dimensions: 4″ ID
Approved Direct Vent Systems: Kingsman flex (Z-Flex) venting kit, M & G-Duravent, Direct Vent system (Duravent Pro), BDM Pro Form Direct Vent, Ameri-Vent Direct Vent Pipe System, ICC Excel Direct, Metal Fab Sure-Seal DV and Selkirk Direct Temp
Actual Viewing Area: 29 3/4″ W x 18 9/16″ H
Valve Type: Millivolt (Standing Pilot)

*Venting Requirements: This unit requires venting pipe with an inner diameter of 4 Inches. Please see the Venting Components section on this page if available for venting pipe that must be used with this unit.

The 36-Inch Kingsman Zero Clearance Clean View Direct Vent Millivolt Gas Fireplace, rated for use as a supplemental heat source, with its tempered glass front and smooth face perimeter, and low profile frame allowing for a clean looking installation is a sleek looking fireplace option. This Kingsman ZCV3622 Fireplace utilizes a lifelike split oak log set made from a durable cast refractory cement, a reliable standing pilot valve which ensures operation even in power outages, and a millivolt valve which allows it to pair with a full line of remotes and wall switches. Kingsman includes a safety barrier screen with this ZCV3622 Fireplace to prevent accidental contact with hot surfaces. BTU Input Ratings: 18,000 Natural Gas / 18,000 Liquid Propane. Efficiency Rating: 61.7% Natural Gas / 63.2% Liquid Propane.
